9 Jan 2017
TE Connectivity Introduces New Generation of Coolsplice Connectors with Extended Wire Range
HARRISBURG, PA., USA – January 9, 2017 – TE Connectivity (TE), a world leader in connectivity and sensors, is introducing a new generation of CoolSplice connectors. This wire-to-wire insulation displacement connector (IDC) splice solution combines reliability with ease of termination. The wire size range has been extended to enable a splice of larger wires.
TE’s new connectors leverage a push button design to ease wire termination and the body of the connector is made from a clear material to allow visual inspection of the termination. Gel-filled sealed versions meet an Ingress Protection IPX8 standard, which means they withstand up to two hours under water at a depth of one meter.
The splice can be made quickly and easily and requires no special tools. The user inserts the insulated wire into an insulation displacement crimp contact and pushes down the button of the connector with standard pliers. Movement of the wire into the insulation piercing contact can be easily seen through the clear housing sidewall.
CoolSplice connectors have two independent buttons that allow users to pre-assemble a single wire and complete the splice later, making it possible to preterminate a wire in the factory and then finish the installation in the field.
Applications for CoolSplice connectors include lighting in outdoor sign and building facades, in commercial refrigeration, in displays and cabinets, as well as in HVAC and security and alarm systems.
The new connectors are suitable for splicing solid and stranded wire between 22 AWG and 18 AWG (0.34 mm2 - 0.75 mm2). Standard connectors have green buttons, while sealed connectors have blue buttons. All are rated 3.5–5 A max at 450 V AC/DC. Their compact size enables them to fit through holes as small as 16 mm.
New larger connectors
TE’s CoolSplice connector portfolio has also been expanded to include IDC connectors suitable for splicing larger wires from 18 AWG to 12 AWG (0.75 mm2 - 4.0 mm2). The connectors have clear bodies with red, yellow and blue color-coded termination buttons to make matching wire size to the appropriate connector an easy task. There are three variants that collectively can splice eight different combinations of wire sizes. Both standard and sealed versions are available.
CoolSplice Large Wire is suitable for use in many types of outdoor public lighting such as roadway, bridge and tunnel lighting, and in home automation applications. Versions accepting 18 AWG wire are rated 10 A max at 600 VAC and VDC, while versions accepting 16 and 14 AWG wire are rated 15 A max at 600 VAC and VDC.
All CoolSplice connectors can be used in temperatures from minus 40 and up to 105 Celsius.
CoolSplice, TE, TE Connectivity and the TE connectivity (logo) are trademarks of the TE Connectivity Ltd. family of companies.
